STATUS
Version 1.0, 02/2015. Copyright 2012 Hitron Technologies
47
Version 1.0, 02/2015. Copyright 2014 Hitron Technologies
47
Hitron CGNVM User’s Guide
2.6 The Status: DOCSIS Event Screen
Use this screen to view information about local WAN activity events.
Click Status > DOCSIS Event. The following screen displays.
Uncorrectables This displays the number of blocks received that
required correction due to corruption, but were unable to
be connected.
Reset FEC Counters Click this to return the Forward Error Connection (FEC)
columns (Correcteds and Uncorrectables).
Upstream Overview
NOTE: The upstream signal is the signal transmitted from the CGNVM.
Port ID This displays the ID number of the upstream
connection’s port.
Frequency (Hz) This displays the actual frequency in Hertz (Hz) of each
upstream data channel to which the CGNVM is
connected.
Modulation This displays the type of modulation that each upstream
channel uses.
SNR (dB) This displays the Signal to Noise Ratio (SNR) of each
upstream data channel to which the CGNVM is
connected, in dB (decibels).
Channel ID This displays the ID number of each channel on which
the upstream signal is transmitted.
Bandwidth This displays the maximum available bandwidth on the
relevant channel.
Table 10: The Status: DOCSIS WAN Screen (continued)
