uuReplacing Light BulbsuFront Fog Light Bulbs
*
696
3. Push the tab to remove the coupler.
4. Rotate the old bulb to the right to remove.
5. Insert a new bulb into the fog light
assembly and turn it to the left.
6. Insert the coupler into the connector of the
bulb.
4. Rotate the old bulb to the left to remove.
5. Insert a new bulb into the fog light
assembly and turn it to the right.
6. Insert the coupler into the connector of the
bulb.
1Front Fog Light Bulbs
*
Insert a flat-tip screwdriver, lift and remove the centre
pin to remove the clip.
Insert the clip with the centre pin raised, and push
until it is flat.
Models with halogen front fog lights
Push until the pin
is flat.
* Not available on all models
