CT47 Mobile Computer Series User Guide 105
N6803 FlexRange Imager Field of View/Resolution
Near Field Optical System
• Horizontal FOV: 48°
•Vertical FOV: 21°
Note: DPI can be calculated based on the following formula:
Horizontal DPI = 1920 pixels/width of horizontal field of view (inches)
Vertical DPI = 800 pixels/width of vertical field of view (inches)
Far Field Optical System
• Horizontal FOV: 20°
•Vertical FOV: 12°
Note: DPI can be calculated based on the following formula:
Horizontal DPI = 1280 pixels/width of horizontal field of view (inches)
Vertical DPI = 800 pixels/width of vertical field of view (inches).
S0703 Imager
The depth of field measurements used the following parameters:
• Distances are measured from the front of the Imager.
• +23 °C (+73 °F), 0 lux for guaranteed, 200 lux for typical.
• Photographic quality codes.
Note: Time to Read and Depth of Field are impacted if the barcode symbol is at the edge of
the image.
Guaranteed Specs
Focus Standard Range
Symbology Near Distance Far Distance
5 mils Code 39 mm 79 270
in. 3.11 10.63
10 mils Code 39 mm 40 450
in. 1.57 17.72
20 mils Code 39 mm 44 674
in. 1.73 26.53
13 mils 100% UPC-A mm 44 515
in. 1.73 20.27
15 mils Code 128 mm 42 572
in. 1.65 22.52
