Enterprise Modular Library E-Series user guide 103
Drive expansion module (8U) with
1 power supply and 4 tape drives
Physical:
Weight
Dimensions (HxDxW)
Electrical:
Input power
Power rating
Input current
41 kg (90.0 lb)
35.6 x 81.1 x 48.0 cm
(14.0 x 31.9 x 18.9 in)
288 Watts
297 VA
1.5 A (at 200 VAC)
Main power supply
Weight 2.3 kg (5.4 lb)
Card cage expansion module power supply
Weight 0.8 kg (1.8 lb)
HP LTO Ultrium drive and tray
Weight 3.6 kg (7.9 lb)
LTO Ultrium cartridge
Weight 220 g (7.8 oz)
HP StorageWorks e2400-FC 2G interface
controller
Dimensions
Power requirements
6U wide x 4HP tall
Voltage Current Power Peak
3.3 VDC 1.5 A 4.95 W 2.85 A for 4 ms
5.0 VDC 2.7 A 13.50 W 3.2 A for 0.7 sec
Total power=18.45 W
HP StorageWorks Interface Manager card
Dimensions
Power requirements
4U wide x 4HP tall
Voltage Current Power Peak
3.3 VDC 0.65 A 2.14 W 2.0 A
5.0 VDC 0.8 A 4.0 W 2.0 A
Total power=6.14 W
Table 25 Library component specifications (continued)
