128 SNMP reference
External details for connUnitSensorTable
12 Firmware Revision for Unified CPLD (Controller B)
13 Firmware Revision for Expander (Controller A)
14 Firmware Revision for Expander (Controller B)
15 Hardware Revision for Controller A
16 Hardware Revision for Controller B
Table 12 connUnitRevsTable index and description values
connUnitRevsIndex connUnitRevsDescription
Table 13 connUnitSensorTable index, name, type, and characteristic values
connUnitSensorIndex connUnitSensorName connUnitSensorType connUnitSensor
Characteristic
1 CPU Temperature (Controller A) board(8) temperature(3)
2 CPU Temperature (Controller B) board(8) temperature(3)
3 FPGA Temperature (Controller A) board(8) temperature(3)
4 FPGA Temperature (Controller B) board(8) temperature(3)
5 Onboard Temperature 1 (Controller A) board(8) temperature(3)
6 Onboard Temperature 1 (Controller B) board(8) temperature(3)
7 Onboard Temperature 2 (Controller A) board(8) temperature(3)
8 Onboard Temperature 2 (Controller B) board(8) temperature(3)
9 Capacitor Temperature (Controller A) board(8) temperature(3)
10 Capacitor Temperature (Controller B) board(8) temperature(3)
11 CM Temperature (Controller A) enclosure(7) temperature(3)
12 CM Temperature (Controller B) enclosure(7) temperature(3)
13 Power Supply 1 Temperature enclosure(7) temperature(3)
14 Power Supply 2 Temperature enclosure(7) temperature(3)
15 Capacitor Pack Voltage (Controller A) board(8) power(9)
16 Capacitor Pack Voltage (Controller B) board(8) power(9)
17 Capacitor Cell 1 Voltage (Controller A) board(8) power(9)
18 Capacitor Cell 1 Voltage (Controller B) board(8) power(9)
19 Capacitor Cell 2 Voltage (Controller A) board(8) power(9)
20 Capacitor Cell 2 Voltage (Controller B) board(8) power(9)
21 Capacitor Cell 3 Voltage (Controller A) board(8) power(9)
22 Capacitor Cell 3 Voltage (Controller B) board(8) power(9)
23 Capacitor Cell 4 Voltage (Controller A) board(8) power(9)
24 Capacitor Cell 4 Voltage (Controller B) board(8) power(9)
25 Capacitor Charge Current (Controller A) board(8) currentValue(6)
26 Capacitor Charge Current (Controller B) board(8) currentValue(6)
27 Power Supply 1 Voltage, 12V power-supply(5) power(9)
