4-12

Using the HP Web Browser Interface

Tasks for Your First HP Web Browser Interface Session

Using the HP Web Browser

Interface

Online Help for the HP Web Browser Interface

Online Help is available for the web browser interface. You can use it by

clicking on the question mark button in the upper right corner of any of the

web browser interface screens.

Figure 4-5. The Help Button

Context-sensitive help is provided for the screen you are on.

Note If you do not have HP TopTools for Hubs and Switches installed on your

network and do not have an active connection to the World Wide Web, then

Online help for the web browser interface will not be available.

For more on Help access and operation, refer to “Help and the Management

Server URL” on page 4-14.

The Help Button
