Removal and Replacement Procedures
Center Wall
To remove the center wall:
1. Power down the server. See “Powering Down the Server” in this chapter.
2. Remove the access panel. See “Access Panel” in this chapter.
3. Remove the PCI riser board assembly. See “PCI Riser Board Assembly” in this chapter.
WARNING: To reduce the risk of personal injury from hot surfaces, allow the internal
system components to cool before touching them.
4. Disconnect the center wall fan cables from the fan connectors on the system board.
Figure 2-19: Disconnecting the center wall fan cables (processor
removed for clarity)
HP ProLiant DL320 Generation 2 Server Maintenance and Service Guide 2-25
