Solid-state drive (SSD)
Description Spare part number
SSD
1 TB, Z Turbo Drive L28490-001
256 GB, Z Turbo Drive L28491-001
512 GB, Z Turbo Drive L28492-001
1 TB, SATA, TLC L30762-001
256 GB, SATA, TLC L30763-001
512 GB, PCIe, SS, NVMe, TLC L28488-001
512 GB, PCIe, NVMe, Self-encrypting drive (SED), Opal 2, TLC L28487-001
512 GB, SATA-3, FIPS-140–2, TLC L28489-001
2 TB, PCIe, NVMe, TLC L28486-001
256 GB, PCIe, SATA-3, SED, Opal2, TLC L28485-001
256 GB, PCIe, NVMe, TLC L28484-001
256 GB, NVMe SED, Opal 2, TLC L28483-001
16 GB, IO L28481-001
NOTE: An additional SSD slot is available under the system board. That part is not a customer self-repair
part.
Before removing the solid-state drive, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the bottom cover (see Service door on page 41).
5. Remove the battery (see Battery on page 43).
Remove the solid-state drive:
1. Remove the Phillips M2.0×2.0 screw (1) that secures the drive to the system board.
46 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
