Fans
Description Spare part number
Right fan, GPU L30389-001
Left fan, CPU L30389-001
NOTE: Models with UMA graphics have only the left fan. Models with discrete graphics have both the left
and right fans.
Before removing the fans, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the any smart cards and memory cards.
5. Remove the bottom cover (see Service door on page 41).
6. Remove the battery (see Battery on page 43).
7. Remove the memory modules (see Memory modules on page 51).
8. Remove the ODD (see ODD on page 48).
9. Remove the SSDs (see Solid-state drive (SSD) on page 46).
10. Remove the middle cover (see Middle cover on page 61).
Remove the left fan:
1. Release the 3 captive screws (1) that secure the fan to the computer.
2. Release the WLAN and WWAN cables (2) from the fan.
3. Disconnect the fan cable (3) from the system board.
70 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
