English – 103
If the fuel pipe needs to be replaced, meas-
ure its length outside of the tank unit and
make a note of the length. This information is
needed when fitting a new pipe.
TANK UNIT
Dismantling
WARNING!
The fuel used in the chain saw
poses the following hazards:
1. The liquid and its vapours are
poisonous.
2. Can cause skin irritation.
3. Is highly inflammable.
The figures on the next page illustrate all
types of mountings between the tank unit and
the engine sub-assembly marked by letters.
Empty the tank and dismantle the cylinder
cover as well as the bar and chain.
Loosen the fuel pipe and disconnect the
throttle cable if fitted.
Dismantle the bolts as shown in the figures
and the table on the next page and lift off the
tank unit from the engine sub-assembly.
If heated handles are fitted remove the con-
nections.
The cable to the switch cannot be removed
before the tank unit and the engine sub-
assembly are separated.
NOTE!
Take care that the fuel pipe and throttle
cable are not damaged.
Cleaning and Inspection
Clean all parts and check the following:
• That the fuel pipe is undamaged.
• That the tank unit is not cracked.
• That the throttle cable runs freely.
• That the AV-system is undamaged For AV-
system see page 107.
• That the tank breather is not blocked or
leaks.
• That the fuel cap does not leak.
• That the fuel pipe bushing seals
• That the fuel filter is not blocked.
The mountings applying to the chain saw in
question is evident from the table on the next
page.
!
Eng, p 83-124 96-09-13, 11.15103
