English – 61
Ignition system
ELECTRICAL SYSTEM
Dismantling
Saws 36 and 41.
• Loosen the flywheel nut and unscrew it 1
turn
• Tap the nut quickly with a hammer so that
the flywheel comes loose
• Remove the nut and flywheel.
Other saws, see next page.
Loosen the cable that runs to the stop
switch from the ignition module.
Release the cables from the guide rail and
remove the guide rail.
In the event of a fault in the ignition system
the ignition module should be checked before
dismantling the ignition system.
Check the ignition module as follows:
• Connect test spark plug 502 71 13-01 to the
HT lead and clamp the test spark plug to the
cylinder.
• Turn the engine over using the starter.
• If the test spark plug sparks the ignition
module is OK.
Remove the cylinder cover and the starter unit.
Remove the spark plug and fit the piston stop.
Eng, p 40-82 96-09-13, 10.2161

Husqvarna 268 Specifications

General

Engine displacement	66.7 cc
Weight	6.2 kg (without cutting equipment)
Fuel tank volume	0.75 liters
Oil tank volume	0.4 liters
Chain pitch	3/8 inch
Bar length	40-70 cm (16-28 in)
