64 – English
ELECTRICAL SYSTEM
• Insert feeler gauge 502 51 34-02
(0.3 mm) between the ignition module
and the flywheel's magnet.
• Push the ignition module towards the
flywheel and tighten the bolts to 4 Nm.
Fit the guide rail, insert the cables and fit
the cable to the ignition module.
Stop switch
The stop switch is described in the section
"Safety equipment". See page 51.
Saws 42, 242, 246, 281 and 288.
Other saws.
Push the HT cable through the spark plug
cover and fit the contact spring using the
pliers.
Slide the spark plug cover over the contact
spring.
Fit the ignition coil, which is located next to
the carburettor and connect the cables.
Fit the starter and cylinder cover.
Fit the starter and cylinder cover.
Make a hole in the HT cable using pliers
502 50 06-01.
Fitting the spark plug cover
Eng, p 40-82 96-09-13, 10.2364

Husqvarna 268 Specifications

General

Engine displacement	66.7 cc
Weight	6.2 kg (without cutting equipment)
Fuel tank volume	0.75 liters
Oil tank volume	0.4 liters
Chain pitch	3/8 inch
Bar length	40-70 cm (16-28 in)
