English – 47
Bar length, L Height, H
15-20 inches 50 cm
21-28 inches 70 cm
29-32 inches 80 cm
L
H
The engine should not be running
during the test.
Test that the chain brake comes on as
follows:
!
WARNING!
After repair, the chain brake
must be checked as set out in
the following instructions.
Checking brake operation
Hold the chain saw above a firm surface.
The distance between the bar and the
surface are shown in the table below.
SAFETY EQUIPMENT
Release the front handle and let the chain
saw rotate around the rear handle.
When the bar nose hits the surface the
chain brake should trip.
Eng, p 40-82 96-09-13, 10.1547

Husqvarna 268 Specifications

General

Engine displacement	66.7 cc
Weight	6.2 kg (without cutting equipment)
Fuel tank volume	0.75 liters
Oil tank volume	0.4 liters
Chain pitch	3/8 inch
Bar length	40-70 cm (16-28 in)
