Husqvarna 268 User Manual

English – 57
Dismantling
Dismantle the starter
See the operating instructions.
Pull out the cord 20-30 cm andinsert it into
the cut-out in the starter pulley rim.
Some saws have several long cut-outs.
Rotate the starter pulley anticlockwise until
the spring-tension on the starter pulley ceases.
Dismantle the starter pulley's centre bolt and
washer.
!
If the starter has a cord guide (A), remove
this
Lift out the starter pulley carefully.
If the cord is to be replaced, cut it off and pull
out the bits from the handle and starter pulley
using a pair of long nosed pliers.
!
WARNING!
Ensure that the spring does not
fly out and cause personal injury!
Wear protective glasses!
If the spring is to be replaced, remove the old
spring from the starter pulley. Some saws
have a protective plate over the spring.
STARTER
WARNING!
If the spring tension is released
when lifting the starter pulley, the
spring can fly out and cause per-
sonal injury!
Wear protective glasses!
A
Eng, p 40-82 96-09-13, 10.2157

Husqvarna 268 Specifications

General

Engine displacement	66.7 cc
Weight	6.2 kg (without cutting equipment)
Fuel tank volume	0.75 liters
Oil tank volume	0.4 liters
Chain pitch	3/8 inch
Bar length	40-70 cm (16-28 in)
