122 – English
CRANKCASE AND CRANKSHAFT
Changing the seals
Dismantling
Before dismantling the seals remove the
following parts:
On the starter side:
• Starter
• Flywheel
• Generator (if fitted)
On the clutch side:
• Chain and bar
• Oil pump
Seals fitted in the crankcase
Use the dismantling tool for the saw in
question and remove the seal as follows:
1. Screw the tool into the seal’s rubber
part.
2. Pull the seal from the crankcase by
turning the handle.
Seals fitted on the oil pump or plastic flange
Press out the seal using a suitable tool.
This section describes how to change the
seals without splitting the crankcase.
Eng, p 83-124 96-09-13, 11.39122

Husqvarna 268 Specifications

General

Engine displacement	66.7 cc
Weight	6.2 kg (without cutting equipment)
Fuel tank volume	0.75 liters
Oil tank volume	0.4 liters
Chain pitch	3/8 inch
Bar length	40-70 cm (16-28 in)
