48 – English
Chain catcher
Description
The chain catcher is intented to catch the
chain if it should break.
The chain catcher has a different design and
is secured differently on the chain saws
described in this manual.
The following designs are used:
• Aluminium angle.
• Plastic angle.
• Fixed roller.
• Rotating roller.
The following securing methods are used:
• Using screws on the crankcase.
• Using screws on the spike.
• Using nuts on the spike.
Replacing
Dismantle the chain and bar. See the oper-
ating instructions
Reassemble the chain and bar. See the
operating instructions
Check the chain catcher and replace if bro-
ken or badly damaged.
The tightening torque is stated in the service
data
SAFETY EQUIPMENT
Eng, p 40-82 96-09-13, 10.1548

Husqvarna 268 Specifications

General

Engine displacement	66.7 cc
Weight	6.2 kg (without cutting equipment)
Fuel tank volume	0.75 liters
Oil tank volume	0.4 liters
Chain pitch	3/8 inch
Bar length	40-70 cm (16-28 in)
