36 – English
Saw 394
▲
■
●
●
●
●
●
5
15
2-4
10-12
6-8
7-9
SERVICE DATA
▲
Character key
Numbers by components that are
bolted refer to the tightening torque
in Nm.
= Locking fluid (Loctite).
▲ = Lubricate using two-stroke oil.
■ = Lubricate using saw chain oil.
● = Lubricate using grease.
Eng, p 2-39 96-09-13, 09.5736

Husqvarna 268 Specifications

General

Engine displacement	66.7 cc
Weight	6.2 kg (without cutting equipment)
Fuel tank volume	0.75 liters
Oil tank volume	0.4 liters
Chain pitch	3/8 inch
Bar length	40-70 cm (16-28 in)
