52 – English
Throttle lock
Remove the tank unit from the engine
assembly. See page 103.
!
WARNING!
The fuel used in the chain saw
poses the following hazards:
1. The liquid and its vapours
are poisonous.
2. Can cause skin irritation.
3. Is highly inflammable.
Dismantle the throttle lock pin (A)
using a punch.
Dismantling
A
SAFETY EQUIPMENT
Turn the throttle lock as
shown in the figure, and lift
it out with the spring from
the cut-out in the handle.
Saw 394
Slide the throttle lock and
remove it forwards as
shown in the figure.
Saws 61, 268, 268K,
272XP, 272K, 272S,
281XP, 288XP and
394.
Saws 61, 268, 272XP, 272K,
272S, 281XP and 288XP.
Continues on next page.
Carefully prise up the lock
from the slot and remove.
Saws 36, 41, 42, 55,
242XP, 246, 51,
254XP, 257 and
262XP.
Other saws.
Saws 40, 45.
See continuation on next page.
Saw 3120.
See continuation on next
page.
Eng, p 40-82 96-09-13, 10.1652

Husqvarna 268 Specifications

General

Engine displacement	66.7 cc
Weight	6.2 kg (without cutting equipment)
Fuel tank volume	0.75 liters
Oil tank volume	0.4 liters
Chain pitch	3/8 inch
Bar length	40-70 cm (16-28 in)
