14 WHEELS, TIRES
102
H01890-10
(ROCKSTAR EDITION)
–
Remove spacer
3
and brake disc guard
4
.
14.2 Installing the front wheel
Warning
Danger of accidents Oil or grease on the brake discs reduces the braking effect.
– Always keep the brake discs free of oil and grease.
– Clean the brake discs with brake cleaner when necessary.
H00935-10
(All FE standard models)
– Check the wheel bearing for damage and wear.
» If the wheel bearing is damaged or worn:
– Change front wheel bearing.
–
Clean and grease shaft seal rings
1
and contact sur-
faces
A
of the spacers.
Long-life grease ( p. 157)
– Insert the spacers.
–
Clean and lightly grease the wheel spindle.
Long-life grease ( p. 157)
– Position the front wheel and insert the wheel spindle.
The brake linings are correctly positioned.
S01631-10
(ROCKSTAR EDITION)
– Check the wheel bearing for damage and wear.
» If the wheel bearing is damaged or worn:
– Change front wheel bearing.
–
Clean and grease shaft seal rings
1
and contact sur-
faces
A
of the spacers.
Long-life grease ( p. 157)
– Insert the spacer and brake disc guard.
– Clean and lightly grease the wheel spindle.
Long-life grease ( p. 157)
– Position the front wheel and insert the wheel spindle.
The brake linings are correctly positioned.
