7 COMBINATION INSTRUMENT
26
7.1 Combination instrument overview
402819-10
1
Overview of indicator lamps ( p. 20) (FE EU)
1
Overview of indicator lamps ( p. 21) (FE US)
2
Left button
3
Display
4
Right button
7.2 Activation
402819-01
Activating combination instrument
The combination instrument is activated when one of the buttons
is pressed or an impulse comes from the wheel speed sensor.
7.3 Message on the combination instrument
401901-01
Possible states
Battery voltage of the combination instrument – Bat-
tery voltage of the combination instrument is too low.
Change combination instrument battery.
Service – A service is due. Contact an authorized
Husqvarna Motorcycles workshop.
7.4 Setting the combination instrument
Condition
The motorcycle is stationary.
401909-01
– Press and hold both buttons for 3 – 5 seconds.
The Setup menu is displayed. The UNIT display flashes.
– Press one of the buttons to select UNIT for the speed in kilo-
meters KM/H or miles M/H.
