12 SERVICE WORK ON THE CHASSIS
68
12.20 Removing the air filter box cover
S03560-11
–
Pull off the air filter box cover sideways in areas
A
,
B
and
C
and take off toward the rear.
12.21 Installing the air filter box cover
S03560-10
–
Attach catch
1
of the air filter box in area
A
and push for-
ward.
–
Engage the air filter box cover in areas
B
,
C
and
D
.
12.22 Removing the air filter
Note
Engine damage Unfiltered intake air has a negative effect on the service life of the engine.
Dust and dirt will enter the engine without an air filter.
– Only operate the vehicle if it is equipped with an air filter.
Note
Environmental hazard Hazardous substances cause environmental damage.
– Dispose of oils, grease, filters, fuel, cleaning agents, brake fluid, etc., correctly and in compliance
with the applicable regulations.
Preparatory work
– Remove the air filter box cover. ( p. 68)
