TECHNICAL DATA 23
149
Screw plug, oil pressure control
valve
M12x1.5 20 Nm (14.8 lbf ft)
Oil drain plug M14x1.5 15 Nm (11.1 lbf ft)
Nut, inner clutch hub M18x1.5 100 Nm (73.8 lbf ft)
Loctite
®
243â„¢
Nut, primary gear wheel M18LHx1.5 120 Nm (88.5 lbf ft)
Loctite
®
243â„¢
Screw plug, oil screen M20x1.5 15 Nm (11.1 lbf ft)
Plug, timing chain tensioner M24x1.5 40 Nm (29.5 lbf ft)
Screw, alternator cover M24x1.5 18 Nm (13.3 lbf ft)
23.3 Capacities
23.3.1 Engine oil
Engine oil 1.0 l (1.1 qt.) Engine oil (SAE 10W/50) ( p. 155)
23.3.2 Coolant
Coolant 1.2 l (1.3 qt.) Coolant ( p. 155)
23.3.3 Fuel
Total fuel tank capacity, approx. (FE EU)
Super unleaded (ROZ 95) ( p. 156) 9.0 l (2.38 US gal)
Total fuel tank capacity, approx. (FE US)
Super unleaded (ROZ 95) ( p. 156) 8.2 l (2.17 US gal)
Fuel reserve, approx. 1.5 l (1.6 qt.)
23.4 Chassis
Frame Central tube frame made of chrome molybdenum
steel tubing
Fork WP XPLOR 5548
Suspension travel
front 300 mm (11.81 in)
rear 300 mm (11.81 in)
Fork offset 22 mm (0.87 in)
Shock absorber WPXACT 5750
Brake system Disc brakes, floating brake calipers
Brake discs - diameter
front 260 mm (10.24 in)
rear 220 mm (8.66 in)
Brake discs - wear limit
front 2.5 mm (0.098 in)
rear 3.5 mm (0.138 in)
Offroad tire pressure
front 1.0 bar (15 psi)
rear 1.0 bar (15 psi)
