VIEW OF VEHICLE 4

13

4.1 View of vehicle, front left (example)

S03544-10

1

Hand brake lever ( p. 17)

2

Clutch lever ( p. 17)

3

Fuel tank filler cap

4

Air filter box cover

5

Side stand ( p. 24)

6

Engine number ( p. 15)

7

Shift lever ( p. 23)
