CONTROLS 6
19
6.8 Turn signal switch (FE EU)
F00261-10
Turn signal switch
1
is fitted on the left side of the handlebar.
Possible states
Turn signal off – The turn signal switch is in the cen-
tral position.
Left turn signal, on – The turn signal switch is turned
to the left.
Right turn signal, on – The turn signal switch is
turned to the right.
6.9 Emergency OFF switch (FE EU)
H03651-11
The emergency OFF switch
1
is fitted on the right side of the
handlebar.
Possible states
Ignition off – In this position, the ignition circuit
is interrupted, a running engine stops, and a
non-running engine will not start.
Ignition on – In this position, the ignition circuit is
closed and the engine can be started.
6.10 Start button
H03651-12
(FE EU)
Start button
1
is fitted on the right side of the handlebar.
S03585-10
(FE US)
Start button
1
is fitted on the right side of the handlebar.
Possible states
• The start button is in the basic position
• The start button is pressed – The starter motor is actuated
in this position.
