23 TECHNICAL DATA
152
Comfort 2.5 turns
Standard 2 turns
Sport 1.5 turns
Rebound damping
Comfort 17 clicks
Standard 15 clicks
Sport 13 clicks
Spring preload 10 mm (0.39 in)
Spring rate
Weight of rider: 65 … 75 kg (143 … 165 lb.) 39 N/mm (223 lb/in)
Weight of rider: 75 … 85 kg (165 … 187 lb.) 42 N/mm (240 lb/in)
Weight of rider: 85 … 95 kg (187 … 209 lb.) 45 N/mm (257 lb/in)
Spring length 260 mm (10.24 in)
Gas pressure 10 bar (145 psi)
Static sag 37 mm (1.46 in)
Riding sag 110 mm (4.33 in)
Fitted length 477 mm (18.78 in)
Shock absorber oil Shock absorber fluid (SAE 2.5)
(50180751S1) ( p. 156)
23.9 Chassis tightening torques
Remaining screws, chassis EJOT PT
®
K60x25‑Z 1 Nm (0.7 lbf ft)
Screw, active carbon filter (FE US) - 5 Nm (3.7 lbf ft)
Screw, combination switch EJOT PT
®
K50x18 2 Nm (1.5 lbf ft)
Screw, intake air temperature sen-
sor (FE EU)
EJOT PT
®
K50x18 0.7 Nm (0.52 lbf ft)
Screw, pressure regulator (FE EU) EJOT PT
®
K60x25‑Z 2.3 Nm (1.7 lbf ft)
Screw, emergency OFF switch
(FE EU)
M4 0.4 Nm (0.3 lbf ft)
Screw, fixed grip M4 5 Nm (3.7 lbf ft)
Loctite
®
243™
Spoke nipple, front wheel M4.5 6 Nm (4.4 lbf ft)
Spoke nipple, rear wheel M4.5 6 Nm (4.4 lbf ft)
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Screw, battery terminal M5 2.5 Nm (1.84 lbf ft)
Screw, frame protector M5 3 Nm (2.2 lbf ft)
Screw, ground wire in tail section M5 5 Nm (3.7 lbf ft)
Screw, intake air temperature sen-
sor (FE US)
M5 3 Nm (2.2 lbf ft)
Screw, shock absorber adjusting
ring
M5 5 Nm (3.7 lbf ft)
Screws on main silencer M5 7 Nm (5.2 lbf ft)
Nut, starter motor M6 4 Nm (3 lbf ft)
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft)
