5-22
3.5-In. Hard Disk Drive Jumper Settings
The configuration of the following jumpers controls the drive’s mode of
operation:
• SP – Slave Present
• DS – Drive Select
• CS – Cable Select
• PK – Park, used as a place to store a jumper
Seagate Hard Disk Drive
Table 5-13 Seagate Hard Disk Drive Jumper Settings
DS CS/SP Description
On Off Drive configured as a Master.
Off Off Drive configured as a Slave.
On On Drive configured as a Master, with an attached Slave
Maxtor Hard Disk Drive
Table 5-14 Maxtor Hard Disk Drive Jumper Settings
J50:Master/Slave Description
On
Only drive in single drive system, or
Master drive in dual drive system
Off Slave drive in dual drive system
