1-8
Table 1- 1 System Board Hardware Interfaces
Item Interface
Video Physical interface is compatible with the IBM Personal
System/2 (PS/2) VGA interface.
Machine Type 2153:
ATI Rage Pro Turbo AGP 2X or 1X VGA on board.
Machine Type 2139:
ATI Rage Pro Turbo AGP 2X to enhance 3D graphical
display performance.
Modem One 56.6 Kbps IBM AT-ISA plug and play modem
adapter card with data/fax/voice features.
Audio CS4235KQ is compatible with Sound Blaster (Creative
Labs, Inc.).
Pointing device IBM PS/2-compatible mouse
Keyboard device IBM PS/2-compatible keyboard
Serial port 9-pin connector with RS232D electrical interface
Parallel port
Supports SPP (IBM PC/XT, PC/AT, PS/2) compatible,
EPP (IEEE 1284 compliance), ECP (IEEE 1284
compliance) interface.
Game port Game port interface for joystick. It also supports MIDI.
USB
M5237 USB controller integrated in the M1543 south
bridge.
CMOS Reset
This system does not deny access to BIOS Setup Utility. Execute “Load BIOS
Default Settings” in BIOS Setup to clear the corrupted CMOS data. See
“Loading the Default Settings” on page 1-13.
