1-24
Operating Requirements
All machines require two power inputs: one on the system unit and one on the
monitor display.
The system units come with a voltage selector switch, allowing selection of
voltage of either 110 Vac or 220 Vac. This switch must be in the 220 Vac
position when the machine is plugged into a 220 Vac electrical outlet.
The required power input for the monitor shipped with the system unit is auto-
sensing type and does not require any voltage switch adjustment.
Special Tools
The following special tool is required to service this system when running
diagnostics program (PC-Doctor):
•
Wrap plugs, P/N 72X8546
