2-16 TS3400 Tape Library Maintenance Information
Specifications
Maintenance Plan
The library consists of two hardware subsystems, the library and the tape drives. The
tape drive is packaged in a common drive canister and each drive canister is a FRU.
When a drive failure occurs, the drive canister is removed and returned to IBM for
repair. The library maintenance package supports the library and the library
interfaces with the tape drives.
Table 2-2. Physical specifications for the library
Physical Specification Measurement
Width 44.5 cm (17.5 in.)
Depth 89.5 cm (35.2 in.)
Height 22.15 cm (8.7 in.)
Weight (library only) 31 kg (68.3 lbs.)
Table 2-3. Electrical specifications for a maximum configuration of the library
Electrical Specification Measurement
Voltage 100 to 240 Vac.
Frequency 50 to 60 Hz
Power consumption (with 2 drives) 117.85 W
Table 2-4. Environmental specifications for the library
Environmental Factor Operating (see Note) Storage Shipping
Drive temperature
16 to 32 °C
(60 to 90 °F)
1 to 60 °C
(34 to 140 °F)
-30 to 60 °C
(-22 to 140 °F)
Relative humidity 20 to 80% 5 to 80% 5 to 100%
Wet bulb temperature 23 °C (73 °F) max. 29 °C (84 °F) max. 29 °C (84 °F) max.
Note: The operating environment of the library must not conflict with the media storage
requirements (refer to the IBM System Storage TS3400 Tape Library Planning and Operator Guide.
The library may be capable of operating at elevated temperatures for an extended period,
however, the temperature could shorten the useful life of media that is stored in the library. If
media is stored in the library for more than 10 hours, the storage temperature requirements
for media should be met. It should be assumed that media stored in the library is
approximately 2 degrees above ambient temperature when the library is powered ON.
Table 2-5. Performance specifications for the library
Performance Factor Condition Measurement
Inventory
Full cartridges with bar code labels 40 sec.
Full cartridges without bar code labels 100 sec.
No cartridges 100 sec.
Average access time (max.)
X direction (one way) 3 sec.
Y direction (one way) 4.5 sec.
Picker direction (one way) 3 sec.
