124 IBM System x3850 X6 and x3950 X6 Planning and Implementation Guide
4.8 PDU and line cord selection
There are a number of power distribution units (PDUs) that can be used to power the X6
system. The size and type of the PDUs that you select will depend on your country voltage,
type, and number of outlets required, and the system and peripheral device power load. You
can use the IBM Power Configurator to assist in determining your total power load.
Download the IBM Power Configurator from the following link:
http://ibm.com/systems/bladecenter/resources/powerconfig.html
This section describes the power supply unit to PDU line cord options available to connect
your X6 power supplies to your PDU source.
4.8.1 Server to PDU power cord options
The PSUs (power supply units) installed in the X6 server have C14 connectors. This means
the line cord you use requires C13 plugs on the server side. One identical power cable is
required for each power supply installed. The default power cable is a 2.8m, 10A/100-250V,
C13 to IEC 320-C14 Rack Power Cable (P46M2982). See Table 4-6 for additional power
cables options for the 900W and 1400W PSUs.
Table 4-6 Server to PDU power cord options
Because of the location of the PSUs at the back of the server, power cables with right angle
plugs will not physically fit into the power supply connector, therefore they are not supported.
Power cable
part numbers
Power cable
feature codes
Description
39Y7937 6201 1.5m, 10A/100-250V, C13 to IEC 320-C14 Rack Power Cable
P46M2982 6311 2.8m, 10A/100-250V, C13 to IEC 320-C14 Rack Power Cable
39Y7938 6204 2.8m, 10A/100-250V, C13 to IEC 320-C20 Rack Power Cable
39Y7932 6263 4.3m, 10A/100-250V, C13 to IEC 320-C14 Rack Power Cable
P47C2498
a
a. This is a Y cable that connects to 2 identical power supply units (PSUs). Y cables can only be used with 900W
PSUs. All other power supplies are not compatible with the Y cable.
A3SS 1.2m, 10A/100-250V, 2 Short C13s to Short C14 Rack Power Cable
P47C2499
a
A3ST 2.5m, 10A/100-250V, 2 Long C13s to Short C14 Rack Power Cable
P47C2500
a
A3SU 2.8m, 10A/100-250V, 2 Short C13s to Long C14 Rack Power Cable
P47C2501
a
A3SV 4.1m, 10A/100-250V, 2 Long C13s to Long C14 Rack Power Cable
P47C2502
a
A3SW 1.2m, 16A/100-250V, 2 Short C13s to Short C20 Rack Power Cable
P47C2503
a
A3SX 2.5m, 16A/100-250V, 2 Long C13s to Short C20 Rack Power Cable
P47C2504
a
A3SY 2.8m, 16A/100-250V, 2 Short C13s to Long C20 Rack Power Cable
P47C2505
a
A3SZ 4.1m, 16A/100-250V, 2 Long C13s to Long C20 Rack Power Cable
