Icom IC-7800 User Manual

q AC power cable*
1
������������� 1
w Antenna jumper cables ����������� 2
e Rack mounting handles ��������� 1 pair
r Screws for rack mounting handles ���� 1 set
t CF (Compact Flash) memory card ������ 1
y Stands ���������������� 1 pair
u Spare fuse (FGB 2 A) ������������ 1
i RCA plugs ���������������� 2
o DC power plug ��������������� 1
!0 2-conductor
1
⁄8″ plugs ������������ 3
!1 3-conductor
1
⁄8″ plugs ������������ 2
!2 3-conductor
1
⁄4″ plugs ������������ 3
!3 ACC plugs (7-pin) ������������� 2
!4 ACC plugs (8-pin) ������������� 2
!5 Antenna connector caps ���������� 4
!6 Main dial*
2
���������������� 1
*
1
May differ from that shown depending on the version
*
2
See the “Information—About the Main Dial” leaflet that
comes with the IC-7800, for dial attachment details.
iii
SUPPLIED ACCESSORIES
q
!0
!1 !2 !3 !4 !6!5
yu io
e
w
r
t
