5-9
5
FUNCTIONS FOR RECEIVE
D USB mouse operation
If you connect a USB mouse to the transceiver, a
mouse pointer appears on the spectrum scope screen.
Now, you can change the frequency by using the
mouse.
The mouse changes the frequency that the scope is
selected in either the Main or Sub band. Or while
holding down [XFC], it changes the transmit fre-
quency.
• Mouse operation on the Center mode
Button Operation Description
Left
Click
The frequency changes to
the clicking point and mouse
pointer move to the center of
the screen.
Drag
The frequency changes to
the clicking point and mouse
pointer move to the center
of the screen, and then the
frequency increases or de-
creases.
Right Click/Drag
The Right button temporarily
changes the frequency.
While holding the button, same
action as the Left button, but
release it to return to the origi-
nal frequency.
• Mouse operation on the Fix mode
Button Operation Description
Left
Click
The frequency and marker
change to the clicking point.
Drag
The frequency and marker
change to the clicking point,
and then the frequency in-
creases or decreases.
Right Click/Drag
The Right button temporarily
changes the frequency.
While holding the button, same
action as the Left button, but
release it to return to the origi-
nal frequency.
To Next Page
