120
SPECIFICATIONS
14
D General
• Frequency coverage : (unit: MHz)
*
1
Guaranteed 440–450 MHz only, *
2
Guaranteed 144–148 MHz only,
*
3
Guaranteed 430–440 MHz only
• Mode : FM, AM (Rx only), WFM (Rx only), DV
†
• No. of memory channels : 1304
(incl. 100 scan edges and 4 call channels)
• Usable temp. range : –20°C to +60°C; –4°F to +140°F
• Tuning steps : 5
‡
, 6.25
‡
, 8.33
‡
, 9
‡
, 10, 12.5, 15, 20, 25,
30, 50, 100, 125 and 200 kHz
• Frequency stability : ±2.5 ppm (–20°C to +60°C; –4°F to +140°F)
• Power supply : 10.0–16.0 V DC for external DC power,
or specified Icom’s battery pack
• Digital transmission speed: 4.8 kbps
†
• Voice coding speed : 2.4 kbps
†
• Current drain (at 7.4 V DC) :
Tx High 144 MHz 2.1 A typical
430/440 MHz 2.2 A typical
Tx Low 0.8 A (approx.)
Rx max. power 340 mA typical (dualwatch; FM/DV
†
)
standby 170 mA typical (dualwatch; FM/DV
†
)
• Antenna connector : SMA (50 Ω)
• Dimensions : 58.4(W)×103(H)×34.2(D) mm;
(projections not included) 2
9
⁄32(W)×4
1
⁄16(H)×1
11
⁄32(D) in
• Weight (approx.) : 300 g; 10.6 oz (with antenna and BP-217)
• Data connector : 3-conductor 2.5 (d) mm; (
1
⁄10˝)
D Transmitter
• Modulation system :
FM Variable reactance freq. modulation
DV (Digital)
†
GMSK reactance freq. modulation
• Output power (at 7.4 V DC) : High 5.0 W, Low 0.5 W (approx.)
• Max. frequency deviation : ±5.0 kHz (FM wide: approx.)
±2.5 kHz
(FM narrow: approx.)
• Spurious emissions : Less than –60 dB
• Ext. mic. connector : 3-conductor 2.5 (d) mm; (
1
⁄10˝)/2 kΩ
Version
U.S.A.
Taiwan
Korean
Australian
Export
A band
Tx: 144–148, 420–450*
1
Rx: 0.495–823.995*
1,
*
2
,
849–868.995,
894–999.990
144–146, 430–432
144–146, 430–440
Tx: 144–148, 420–450*
3
Rx: 0.495–999.990*
2,
*
3
Tx: 137–174*
2
, 400–470*
3
Rx: 0.495–999.990*
2,
*
3
B band
Tx: 144–148, 420–450*
1
Rx:
118–174*
2
, 350–470*
1
144–146, 430–432
144–146, 430–440
Tx: 144–148, 420–450*
3
Rx:
118–174*
2
, 350–470*
3
Tx:
137–174*
2
, 400–470*
3
Rx:
118–174*
2
, 350–470*
3
†
Available for the IC-91AD or when UT-121 is installed into the IC-91A.
‡
Selectable depending on the operating frequency band.
