31
6
REPEATER AND DUPLEX OPERATIONS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
■ Duplex operation
D Setting offset frequency
q Enter “OFFSET FREQ” in DUP/TONE… set mode. (p. 97)
w Rotate [DIAL]
†
to set offset frequency.
• 1 MHz and 10 MHz tuning steps are available by pushing and
holding [MHz](VFO) for 1 sec.: push [MHz](VFO) to cancel it.
e Push [ï](5) (or [
ΩΩ
](4)) to return to DUP/TONE… set mode,
and push [MENU/LOCK] to return to frequency indication.
D Setting duplex direction
➥ Push and hold [DUP](4) for 1 sec. to select “–DUP” or
“+DUP”.
•“–DUP” or “+DUP” indicates the transmit frequency for minus
shift or plus shift, respectively.
• When offset frequency is 0.6 MHz.
U.S.A. and Korean versions:
Auto repeater function has priority over the manual duplex
setting. If the frequency changes after setting, the auto re-
peater function may have changed the duplex setting.
MENU screen ➪ DUP/TONE… ➪ OFFSET FREQ
(Push [MENU/LOCK]) (Rotate [DIAL]
†
, then push [ï](5)
†
.)
Although [DIAL] and [ï](5) are used for description in this
section, [
∫∫
](2)/[
√√
](8) and [
≈≈
](6) are available instead of
[DIAL] and [ï](5).
†
[DIAL] ↔ [
∫∫
](2)/[
√√
](8) [ï](5) ↔ [
≈≈
](6)
