15-9
o The screen at left is displayed.
• The following dialog appears in the IC-R9500 display.
RWARNING!: NEVER turn the IC-R9500 power
OFF at this stage.
The receiver firmware will be corrupted.
!0 Click [OK] to finish the firmware update.
• The “FIRMWARE UPDATING” dialog as above disap-
pears.
!1 Push [POWER] to turn the IC-R9500 power OFF,
then ON again.
!2 Depending on the status of the update process, ei-
ther of dialogs at left will appear in sequence.
RWARNING!: NEVER turn the IC-R9500 power
OFF at this stage.
The receiver firmware will be corrupted.
!3 After the dialog disappears, the firmware update is
completed and the normal operation screen ap-
pears.
RX-DSP UPDATING...
Please wait for 20sec.
WARNING! NEVER turn power OFF.
Please wait for 45sec.
WARNING! NEVER turn power OFF.
Firmware up dating for the main CPU is completed.
The sub CPU and/or DSP firmware update will start automatically depending on the updated contents,
and this will take approx. 2 minutes.
Turn the IC-R9500 power OFF, then ON again with [POWER] switch.
After turning the power ON, the IC-R9500 will work with the updated firmware.
DO NOT turn the IC-R9500 power OFF until the normal operational screen appears.
Click [OK] to finish the firmware update.
iR9500
COMMUNICATIONS RECEIVER
IC-R9500 IP Address
IC-R9500 IP Address
Firmware File Name
Version 1.00
(C) 2006 Icom Inc.
Firmware File Name
Connecting to the IC-R9500.
Connected to the IC-R9500.
Transfer in progress...
Transfer successful.
Start update.
Please wait a while.
IC-R9500 Firm Utility
