Icom ID-51A User Manual

9
D-STAR OPERATION <ADVANCED>
9-21
■ Digital squelch functions (Continued)
D Setting the digital code squelch
q Hold down for 1 second.
• The DR screen is displayed.
• To use the digital call sign squelch function in another
mode, push [V/MHz]
or [M/CALL] to select the
VFO, Memory, or CALL channel mode.
w Push [QUICK] .
e Push D-pad() to select “DSQL,” and then push D-
pad(Ent).
D-pad
()
(Ent)
r Push D-pad() to select “CSQL S” or “CSQL.”
• CSQL S: Turn ON the digital code squelch pocket
beep.
• CSQL: Turn ON the digital code squelch.
t Push D-pad(Ent) to set the digital code squelch, and
then exit the quick menu screen.
• “CSQL S” or “CSQL” appears.
y Push [MENU] .
u Push D-pad() to select the root item (“DUP/
TONE...”), and then push D-pad(Ent).
i Push D-pad() to select “Digital Code,” and then
push D-pad(Ent).
o Rotate [DIAL] to select a digital code between 00
and 99 for the digital code squelch function.
!0 Push [MENU] to save and exit the MENU
screen.
!1 When the received signal includes a matching code,
the squelch opens and the audio is heard.
• When the received signal’s code does not match, the
digital code squelch does not open. However, the S/RF
meter shows the received signal strength.
D Pocket beep function with the digital
code squelch
When a received signal matches your digital code, the
transceiver sounds beep tones for 30 seconds and
“S” blinks.
➥ Push [PTT] to answer, or push D-pad(Ent) to stop
the beeps and the “S” blinking.
• “S” disappears.
If no operation is performed for 30 seconds, the beep
tones automatically stop, but “S” continues to blink
to indicate you received a call.
Appears
Beep, Beep, Beep...
• When “CSQL S” is selected
NOTE: While operating in the low-speed data commu-
nication mode, the digital code squelch opens even if
receiving a signal does not match to your digital code.
