Inovance Monarch NICE 3000 new Series User Manual

6 Parameter Description
-
198
-
The following parameter values list the functions that can be set for DI terminals. If
a certain function cannot be set, check whether this function has been allocated to
another terminal or is running.
NOTE
Parameter values that can be set repeatedly
◆
04/36: Safety circuit feedback NO/NC; 05/37: Door lock circuit feedback NO/
NC; 06/38: RUN contactor feedback NO/NC; 07/39: Brake contactor feedback
NO/NC; 26/58: Brake travel switch 1 NO/NC
The meanings of the NO setting of the functions is as follows (NO value + 32 for the NC
setting).
■
00: Invalid
Even if there is signal input to the terminal, the system has no response. You can
allocate this signal to terminals that are not used to prevent malfunction.
■
01: Up leveling signal
■
02: Down leveling signal
■
03: Door zone signal
The NICE3000
new
system determines the elevator leveling position based on the
󶍾
single door zone switch, up and down leveling switches, and door zone switch
plus the up/down leveling switch. If three leveling switches are used, the system
󶙓
󶙓󶙓
󶙓
󶙓
󶙓󶙓󶙓
down direction. If the leveling signal is abnormal (stuck or unavailable), the system
reports fault Err22.
■
04: Safety circuit feedback
■
05: Door lock circuit 1 feedback
■
29: Safety circuit 2 feedback
■
31: Door lock circuit 2 feedback
The safety circuit is important to safe and reliable running of the elevator, and the
door lock circuit ensures that the hall door and car door are closed before the elevator
starts to run. Valid feedback signals of the safety circuit and door lock circuit are
necessary to elevator running.
It is recommended that these signals are set to NO input. If they are set to NC input,
the system considers
the input active even though there is no input. In this case, the actual state of the
safety circuit cannot be detected, which may cause potential safety risks.
■
06: RUN contactor feedback
■
07: Brake contactor feedback
