6 Parameter Description
-
252
-
Function
Code
Name Setting Range Default Unit
Property
Fd-31 Expansion board 1: Y1 output
0: Reserved
1: Door machine 1 open
2: Door machine 1 close
3: Door machine 2 open
4: Door machine 2 close
5: Brake and RUN
contactors healthy (no
faults E37 and E36)
6: Fault state (output at
level 3, 4, and 5 faults)
7: Running monitoring
(
NICE3000
new
in running
state)
8: Synchronous motor
self-lock output
9: Controller healthy
10: Buzzer tweet
11: Higher-voltage startup
of brake (continuous 4s)
12: Elevator running in up
direction
13: Lamp/Fan running
14: Medical sterilization #
15: Non-door zone stop #
16: Electric lock #
17: Non-service state
18: Emergency evacuation
completed
19: Fire emergency
operation
20: Power failure
emergency output
21: Door lock signal
22: Night output signal
0 -
★
Fd-32 Expansion board 1: Y2 output 0 -
★
Fd-33 Expansion board 1: Y3 output 0 -
★
Fd-34 Expansion board 1: Y4 output 0 -
★
Fd-35 Expansion board 1: Y5 output 0 -
★
Fd-36 Expansion board 1: Y6 output 0 -
★
Fd-37 Expansion board 1: Y7 output 0 -
★
Fd-38 Expansion board 1: Y8 output 0 -
★
Fd-39 Expansion board 1: Y9 output 0 -
★
Fd-40
Expansion board 1: Y10
output
0 -
★
Fd-41 Expansion board 2: Y1 output 0 -
★
Fd-42 Expansion board 2: Y2 output 0 -
★
Fd-43 Expansion board 2: Y3 output 0 -
★
Fd-44 Expansion board 2: Y4 output 0 -
★
Fd-45 Expansion board 2: Y5 output 0 -
★
Fd-46 Expansion board 2: Y6 output 0 -
★
Fd-47 Expansion board 2: Y7 output 0 -
★
Fd-48 Expansion board 2: Y8 output 0 -
★
Fd-49 Expansion board 2: Y9 output 0 -
★
Fd-50
Expansion board 2: Y10
output
0 -
★
These parameters are used to set the functions of 10 relay outputs on MCTC-KZ-G1.
The system supports up to two I/O expansion cards with up to 20 output terminals.
