Appendix A — Specifications and Default Settings

108 CS40 Mobile Computer User’s Manual

CS40 Micro-AB USB Connector Specifications

The CS40 has a standard Micro-AB USB connector:

• 1 A maximum charge when using the universal cell phone charger

accessory

• maximum VBUS output power of 5 V @ 100 mA

CS40 Docking Connector Specifications

The CS40 has an array of seven pin surface contacts that provide USB

“On the Go” (OTG) connectivity and charge power while docked.

CS40 Docking Connector Specifications

Codabar Matrix 2 of 5

Codablock A Maxicode

Codablock F Micro PDF417

Code 11 MSI

Code 39 PDF417

Code 93 Planet

Code 128/GS1-128 Plessey

DataMatrix Postnet

DutchPost QR Code

EAN/UPC Standard 2 of 5

GS1 Composite SwedenPost

GS1 DataBar Expanded Telepen

GS1 DataBar Limited TLC 39

GS1 DataBar Omni-Directional

Pin Number Signal Name Description

1 VEXT Computer power

2 ID Identification pin

3 VBUS VBUS (5 V @ 100 mA max)

4D- USB data signal

5D+ USB data signal

6 GND Ground (power return)

7 GND Ground (power return)
