Appendix A — Specifications and Default Settings
CS40 Mobile Computer User’s Manual 109
EA11 Area Imager Minimum Reading Distances
Minimum distances are measured in the dark (0 lux).
EA11 Minimum Reading Distances
8"
4"
6"
2"
0"
2"
4"
in
6"
8"
10"
10"
cm
10
5
0
5
10
15
20
20
15
25
25
0 5040302010
0" 16"12"8"4"
PDF417 6.6 mils
0.125mm / 5mils
0.25 mm / 10 mils
0.5 mm / 20 mils
Data Matrix 7.5 mils
100% contrast UPC EAN
Symbology Density Minimum Distance Maximum Distance
Code 39 0.125 mm (5 mil)
0.20 mm (8 mil)
0.25 mm (10 mil)
0.50 mm (20 mil)
7.26 cm (2.86 in)
3.96 cm (1.56 in)
3.45 cm (1.36 in)
4.98 cm (1.96 in)
12.09 cm (4.76 in)
20.98 cm (8.26 in)
25.04 cm (9.86 in)
40.28 cm (15.86 in)
UPC/EAN 0.33 mm (13.0 mil) 4.98 cm (1.96 in) 29.62 cm (11.66 in)
Data Matrix 0.191 mm (7.5 mil)
0.254 mm (10 mil)
0.381 mm (15 mil)
3.71 cm (2.46 in)
5.98 cm (2.35 in)
*
16.41 cm (6.46 in)
20.73 cm (8.16 in)
27.58 cm (10.86 in)
