ENGINE COOLING
The c ooling system is reponsible for cooling the engine casing and the engine lubrication oil inside the heat exchanger (2).
From the c irculation pump (1), the coolant is sent to the heat exchanger (2) where the engine lubrication oil is cooled.
From here the coolant reaches the engine block and, after having cooled the cylinders, is sent to the thermostat casing.
Depending on the temperature, the coolant is either recirculated by the water pump (1) or sent to the radiator.
Figure 6
103273
1. Circulation pump - 2. Engine lubrication water/oil heat exchanger - 3. Thermostat casing
8
SECTION 1 - GENERAL SPECIFICATIONS
VECTOR 8 ENGINES
Base - April 2006 Print P2D32V001E
