Iveco VECTOR 8 User Manual

Figure 6
Main mechanical components of the fuel system
Fuel pre-filter for G-DRIVE and SPRINKLER applications
The fuel pre—filter, a water separation type, has the water sensor (4) at the base of the cartridge (3) to indicate if there is water
in the fuel.
The manual priming pump (2) is located on the filter mounting (1).
1. Filter support — 2. Manual priming pump and system bleed — 3. Fuel pre—filter cartridge — 4. Water sensor
103268
SECTION 2 - FUEL
9
VECTOR 8 ENGINES
Print P2D32V001E Base - April 2006
