jcb 2CX User Manual

3 - 1
Section H
Steering
9803/7130
Section H
3 - 1
Issue 1
Basic System Operation
Steer System Schematics
Component Key:
P Pump
T Tank
7 Priority Valve
10 Front Steer Ram
11 Rear Steer Ram
42 Steer Unit
45 Steer Setting Valve
Note: Hydraulic component port identification letters are
shown in parenthesis, e.g. (LS). The same letters will be
stamped on the actual component.
A388440
P
(P)
(PP)
(LS)
(CF)
(LS)
(P) (R)
(L)
(T)
(EF)
T
42
7
45
11
10
