1 - 1
Section A Attachments
9803/7130
Section A
1 - 1
Issue 1
Service Tools
Airmaster Compressor Service Tool Kit
1 Plate - Bearing and Rotor Removal
2 Stud (long) - Bearing and Rotor Removal
3 Stud (short) - Bearing and Rotor Removal
4 Spacer (Plate) - Bearing and Rotor Removal
5 Bolt (M8 X 110)
6 Clamp - Rotor Locking
7 Screw (M10 X 45)
8 Bridge - Rotor Assembly
9 Extractor - Ball Bearing
10 Clamp - Seal Assembly Tool
11 Sling Pin - R.H.
12 Puller - Inner Bearing and Sleeve
13 Screw (M8 X 25)
14 Sling Pin - L.H.
15 Drift - Oil Seal
16 Drift - Oil Seal
17 Drift - Roller Bearing
18 Washer - Sling Pin L.H.
19 Drift - Roller Bearing - Inner
892/00877 Airmaster, Air Test Silencer - safety
device, attach to air delivery cocks when
cocks are to be opened with no hose
attached.
S254270
892/00878 Airmaster, Diaphram Assembly Tool -
Suction Unloader, tool shown in position
S251870
S212010
