30 - 6
Binary Pressure Switch
- Removal and Replacement
The pressure switch is located adjacent to the expansion
valve S on the HVAC/air conditioning unit, beneath the right
hand side console.
!
WARNING
Goggles and rubber gloves must be worn when pressure
switches are removed or fitted. A small amount of
refrigerant is released which can be harmful to the skin
and eyes.
BF 1-10
Removal
1 Disconnect the battery.
2 Gain access to the HVAC unit by removing the right
hand side console, refer to HVAC/Air Conditioning
Unit - Removal and Replacement Step 2.
3 Disconnect the electrical connections and unscrew the
pressure switch.
Replacement
1 Screw the pressure switch into the pressure switch port
and torque tighten sufficiently to form a gas-tight seal.
2 Run the air conditioning and check the pressure
switches for leaks. If any leaks are found, tighten the
pressure switch further until the leaking stops.
Section B Body & Framework
9803/3280
Section B
30 - 6
Issue 1
Air Conditioning
