93 - 1
Hub-Dismantling & Assembly
The procedures for dismantling and assembling the hub on a
PD70 axle are virtually the same as for a SD80 axle -
described on the previous pages (F/92-1 to F/92-4).
However, note that the wheel bearing carrier (shown as item
15 on page F/92-1) is mounted directly on to the axle arm.
Disregard references to the hub carrier (shown as item 21 on
page F/92-1).
Section F Transmission
9803/3280
Section F
93 - 1
Issue 1
Rear Axle - PD70
