jcb 4CX Service Manual

Electrics
Harness Data
Section C Section C
9803/3280 Issue 1
150-2
150-2
2
43
8
7
CA
NH
C10†
CS
CP
N
G
B
S
ME
C10
C10
LA
C40
CR
LC
FA LA
LB
CB
1
6
5
10
11
9
A408780
Harness Interconnection (continued)
SIDE CONSOLE HARNESS -
Main components connected
to this harness:
Side console instruments
Side console switches
Side console warning lamps
Starter switch
Heater controls
Fuses and Relays
Immobiliser (if fitted)
ENGINE/MAINFRAME
HARNESS - Main components
connected to this harness:
Alternator
Starter motor
Primary fuses
Front steer proximity switch
Shovel reset proximity switch
ESOS
Smooth ride solenoids
Air conditioning compressor
FRONT CONSOLE HARNESS -
Main components connected
to this harness:
Left and right column switches
Gearbox control relays
ShiftMaster E.C.U. (if applicable)
Front wiper motor
Front console switches
Speedometer
Front console warning lamps
TRANSMISSION HARNESS -
†Connector C10 is labelled GA
on Synchro Shuttle machines.
Main components connected to
this harness:
Gearbox control solenoids
8
LC
C10
LA
CA
CB
NH LB
LA C10 C10 ME
6
7
6
6
1
1
7
2
2
9
8
6
11
10
5
4
2
3
9
11
10
5
CP
CS
FA
C40
CR
B
S
N
G
2
A408820
C1 C3
C2
C4
C5
C6 C7
Access Details
C1 Inside cab - remove loader
control console.
C2 Inside cab - remove side
console.
C3 Inside cab, rear of heater unit
Remove side console.
C4 Inside cab - remove
front/steer console.
C5 Outside cab - lift bonnet
C6 Under machine above
gearbox. (Powershift shown).
C7 Under machine, located in cab
floor above rear wheel -
remove protective cover.
