jcb 4CX Service Manual

61 - 6
Section E
Hydraulics
9803/3280
Section E
61 - 6
Issue 2*
Excavator Valve
CLAMP
BOOM
BOOM
BOOM
BOOM STABILISER
STABILISER
DIPPER
DIPPER
DIPPER
DIPPER
CROWD
CROWD
CROWD
CROWD
SLEW
SLEW
SLEW
SLEW
ISO EXCAVATOR VALVE
CLAMP
BOOM
BOOM
BOOM
BOOM
STABILISER
STABILISER
DIPPER
DIPPER
DIPPER
DIPPER
CROWD
CROWD
CROWD
CROWD
SLEW
SLEW
SLEW
SLEW
JCB EXCAVATOR VALVE
S270740
S270750
Dismantling and Assembly
- Hoses and Pipes (Sideshift Valve)
Refer to Excavator Valve, Removal and Replacement for
valve block removal and replacement procedure. Hoses and
pipes (when applicable) must be re-connected and phased in
same position as removal.
