JUKI APW-896/IP-420 User Manual

− 52 −
. . . Item that is not displayed due to other setting state
No. Item
Setting range
/
Edit unit
Initial value
Flap concealed stitching data (Right sewing end)
Position of sewing end of right-hand ap is adjusted.
＊
It is possible to set only when is set to ap sewing.
–9.9 to 9.9
/
0.1mm
0.0mm
Changeover of deection direction at the start of sewing
Changeover of deection direction at the start of sewing is performed.
- - -
Deection amount at the start of sewing
In case the start of sewing is the slant sewing setting, deection amount
is compensated. In case the start of sewing is the parallel sewing setting,
deection amount cannot be compensated.
0.5 to 10.0
/
0.1mm
0.0mm
Changeover of deection direction at the end of sewing
Changeover of deection direction at the end of sewing is performed.
- - -
Deection amount at the end of sewing
In case the end of sewing is the slant sewing setting, deection amount
is compensated. In case the end of sewing is the parallel sewing setting,
deection amount cannot be compensated.
0.5 to 10.0
/
0.1mm
0.0mm
Center knife actuating position setting
Cutting position of center knife at sewing start/sewing end is set.
＊
Be sure to adjust with every gauge so that the position meets the top of
letter V of corner knife.
0.0 to 25.0
/
0.1mm
7.0mm
Sewing start center knife
position
Sewing end center knife
position
Corner knife actuating position at sewing start
Cutting position of corner knife at sewing start is set.
–9.9 to 9.9
/
0.1mm
0.0mm
Corner knife actuating position at sewing end
Cutting position of corner knife at sewing end is set.
–9.9 to 9.9
/
0.1mm
0.0mm
