− 61 −
No. Item
Setting range
/
Edit unit
Initial value
Jump feed speed up to the position of corner knife
Jump feed speed up to the position of corner knife is set.
3 to 10
/
1
5
Dart stretcher device stop/motion change-over
Stop/motion of dart stretcher device is selected.
＊
It is possible to set only when dart stretcher option is used.
- - -
Stop Motion
Automatic interlining supplying device stop/motion change-over
Stop/motion of automatic interlining supplying device is selected.
＊
It is possible to set only when automatic interlining supplying
option is used.
＊
Regarding the interlining supplying, when the pattern is not used, be
careful not to make the interlining come out from the top surface of the
table. When using next, press once the feeding button on the panel
and perform the feeding motion to cut.
- - -
Stop Motion
Flap length
Length of ap is set.
It is possible to set only when automatic interlining supplying
device is selected to motion and
sewing mode changeover is
selected to ap sewing.
＊
This setting is set to determine the interlining feeding length of
automatic interlining supplying device. Sewing length is determined by
the detection of ap sensor.
37.0 to
220.0
/
0.1mm
150.0mm
Sewing speed under the high-speed mode
Number of revolutions at lockstitch section is set.
＊
It is possible to set only when
sewing speed setting selection is
set to pattern data selection.
1000 to
3000
/
100sti/min
2500sti/min
Sewing speed under the low-speed mode
Number of revolutions at condensation and back tack sewing sections is
set.
＊
It is limited by
sewing speed under the high-speed mode.
＊
It is possible to set only when sewing speed setting selection is
set to the selection of pattern data.
1000 to
2500
/
100sti/min
1500sti/min
. . . Item that is not displayed due to other setting state
